TIANQIU
LR1130 Battery - 1.5V Alkaline Coin Cell
The LR1130 alkaline 1.5V coin cell — 11.6mm diameter, 56mAh capacity. Ideal for watches, calculators, digital thermometers.
What are the specifications of a LR1130 battery?
The LR1130 is a Alkaline coin cell rated 1.5V, with a nominal capacity of 56mAh. It measures 11.6mm across and 3.1mm thick, and weighs 1.1g. The table below gives the full specification — final values are confirmed on the OEM spec sheet for your project.
| Chemistry | Alkaline |
|---|---|
| Voltage | 1.5V |
| Diameter | 11.6mm |
| Thickness | 3.1mm |
| Capacity | 56mAh |
| Weight | 1.1g |
| Compatible | LR1130 = LR1130H = AG10 = LR54 = 189 = GP89A |
Specs for reference — final values per OEM project.
What batteries are equivalent to the LR1130?
The LR1130 is interchangeable with any cell of the same diameter, thickness and voltage, so an equivalent can be substituted without changing the device. Buyers look these cells up under three numbering systems at once — IEC, ANSI and manufacturer codes — and the list below covers the names the LR1130 is sold under.
Look any number up in the cross-reference tool → — type the marking on your cell and see where it lands, or pick your device and see the cells we supply for it.
Alkaline — same chemistry, direct replacement (1.5V)
This is the family our LR1130 belongs to.
| Number on the cell | Published by |
|---|---|
| AG10 | Energizer cross-reference · Duracell |
| LR54 | Varta data sheet (IEC type) · Duracell · Energizer |
| 189 | Energizer cross-reference · Duracell (Varta column) |
| GP89A | Energizer cross-reference · Duracell |
| V10GA | Varta data sheet · Duracell |
| KA54 | Duracell (Panasonic column) — single source, treat as unconfirmed |
Silver oxide — same size, different chemistry (1.55V)
Fits the same holder and is the better choice where the device needs a stable voltage over a long life (watches, medical, thermometers). It is not a like-for-like swap on price or discharge curve.
| Number on the cell | Published by |
|---|---|
| 389 / 390 | Energizer · Renata · Duracell (D 389/390) |
| SR1130W / SR1130SW | Energizer · Renata · Duracell |
| V389 / V390 | Energizer · Renata (Varta column) |
| SB-AU | Renata cross-reference (Seiko column) · Energizer |
| 280-24 | Renata cross-reference (Citizen column) — single source, treat as unconfirmed |
Where is the LR1130 battery used?
The LR1130 is used in watches, calculators, digital thermometers and other compact devices that draw small currents over long periods. Its 1.5V output and 56mAh capacity suit equipment that has to run for months without a battery change. The blocks below set out what to check for each device type.
What do buyers ask about the LR1130 battery?
Need the LR1130 priced, or the same cell printed and packed under your own brand? Send the quantity, the target market and the packaging format, and we return price, MOQ band and the LR1130 data sheet.
Printed, blister-carded and boxed in our own plant, from 50 cartons per product line. Samples are available before a production run — tell us the device the cell goes into.
LR1130 Battery FAQs
What is a LR1130 battery?
What is the LR1130 compatible with?
What is a LR1130 battery equivalent to?
Is the LR1130 rechargeable?
How long does a LR1130 battery last?
Does a LR1130 fit my device?
How do I get LR1130 battery wholesale pricing?
Pricing depends on cell grade, quantity and packaging, so quotes are issued per project rather than from a fixed list. Send your quantity, target market and label or packaging requirements, and we return a landed-cost quote together with samples — usually within one working day.
