CR2032 Battery - 3.0V Lithium Coin Cell
The CR2032 lithium 3.0V coin cell — 20mm diameter, 190mAh ~ 255mAh capacity. Ideal for car key fobs, motherboard cmos, electronic scales.
What are the specifications of a CR2032 battery?
The CR2032 is a Lithium coin cell rated 3.0V, with a nominal capacity of 190mAh ~ 255mAh. It measures 20mm across and 3.2mm thick, and weighs 2.9-3.1g (only for reference). The table below gives the full specification — final values are confirmed on the OEM spec sheet for your project.
| Chemistry | Lithium |
|---|---|
| Voltage | 3.0V |
| Diameter | 20mm |
| Thickness | 3.2mm |
| Capacity | 190mAh ~ 255mAh |
| Weight | 2.9-3.1g (only for reference) |
| Compatible | CR2032 = 5004LC = ECR2032 = KCR2032 = DL2032 |
Specs for reference — final values per OEM project.
CR2032 vs CR2025 vs CR2016
All three are 20mm, 3V lithium coin cells — but they differ in height. The CR2032 is the tallest of the three, so it only fits holders designed for a 3.2mm cell. Check your device's battery bay before swapping.
| CR2032 | CR2025 | CR2016 | |
|---|---|---|---|
| Diameter | 20mm | 20mm | 20mm |
| Thickness | 3.2mm | 2.5mm | 1.6mm |
| Voltage | 3V | 3V | 3V |
| Capacity | ~220mAh | ~165mAh | ~90mAh |
What are the CR2032 battery characteristics?
These are the CR2032 performance figures we declare under EU Regulation 2023/1542: rated capacity and the maximum available duration under a standard continuous load. Real discharge performance depends on load, temperature and cut-off voltage, so the exact test conditions are stated underneath the table.
| Capacity | MAD | Application duration |
|---|---|---|
| 190mAh / 0.57Wh | 950hours | 17.0hours |
| 210mAh / 0.63Wh | 1050hours | 18.0hours |
| 220mAh / 0.66Wh | 1150hours | 19.0hours |
| 240mAh / 0.72Wh | 1200hours | 20.0hours |
| 255mAh / 0.765Wh | 1250hours | 21.0hours |
Capacity & MAD test condition: 15kΩ continuously to 2.0V @ 20±2℃
Application-Electronic key: 10mA 5s on, 55s off 24h/day to 1.8V @ 20±2℃
Shelf life: One year after delivery under normal storage, 98% of initial capacity maintained
EU Declaration No. TQ-EUDOC-CR2032-20260418 · Compliant with Regulation (EU) 2023/1542
What batteries are equivalent to the CR2032?
The CR2032 is interchangeable with any cell of the same diameter, thickness and voltage, so an equivalent can be substituted without changing the device. Buyers look these cells up under three numbering systems at once — IEC, ANSI and manufacturer codes — and the list below covers the names the CR2032 is sold under.
Look any number up in the cross-reference tool → — type the marking on your cell and see where it lands, or pick your device and see the cells we supply for it.
Same cell, other designation or brand code — direct replacement
| Number on the cell | Published by |
|---|---|
| 5004LC | ANSI / NEDA designation for this size — Energizer CR2032 product datasheet, printed as “Designation: ANSI / NEDA-5004LC, IEC-CR2032” (data.energizer.com) |
| ECR2032 | Energizer (own model) · Maxell cross-reference chart, Energizer Eveready column |
| DL2032 | Duracell (own code) · Maxell cross-reference chart, Duracell column · Energizer CR2032 product page replacement list |
| KECR2032 | Rayovac (own code) · Maxell cross-reference chart, Rayovac column — single source, treat as unconfirmed |
| SB-T15 / ST-T15 | Seiko (own code) · Renata CR2032 cross-reference guide and the Energizer CR2032 product page, which prints it as ST-T15; Maxell's chart prints SB-T51 — the charts disagree on the suffix, so read the marking on the cell |
| CR2032 — the same code is printed by Maxell, Panasonic, Murata, Toshiba, Varta, Renata and Rayovac | Renata CR2032 cross-reference guide, which names each maker's code for this size · Maxell cross-reference chart |
| KCR2032 | Kodak code in trade listings and in our own model data — not found in the Maxell chart or Renata's cross-reference guide, and the trade listings that do print it disagree about whose code it is — single source, treat as unconfirmed |
Fits the holder, different chemistry — not a like-for-like swap
Energizer's own note on its coin cells is the one to keep in mind: coin lithium batteries are not interchangeable, because both the diameter and the thickness vary with the cell designation — fit the designation your device specifies.
| Number on the cell | Published by |
|---|---|
| BR2032 | Energizer CR2032 product page lists BR2032 in its replacement list · Renata and Maxell both print this size as “CR/BR2032” — BR is lithium carbon monofluoride (Li-CFx), not lithium manganese dioxide: same 20.0 × 3.2 mm can, different discharge curve and usually lower capacity |
Same diameter, thinner cell — contact depends on the holder
A thinner cell of the same diameter drops into many holders, but the contact pressure comes from the holder's spring. If the device specifies CR2032, fit CR2032.
| Number on the cell | Published by |
|---|---|
| CR2025 | IEC 60086 size designation, 20.0 × 2.5 mm — 0.7 mm thinner than CR2032; 170 mAh typical against our CR2032's 190–255 mAh |
| CR2016 | IEC 60086 size designation, 20.0 × 1.6 mm — 1.6 mm thinner than CR2032; 100 mAh typical |
Where is the CR2032 battery used?
The CR2032 is used in car key fobs, motherboard cmos, electronic scales and other compact devices that draw small currents over long periods. Its 3.0V output and 190mAh ~ 255mAh capacity suit equipment that has to run for months without a battery change. The blocks below set out what to check for each device type.
CR2032 in Car Key Fobs
Most modern car key fobs and remote controls run on a CR2032 coin cell. Nissan, Honda and Toyota remotes commonly use the CR2032 (check the exact cell printed inside before ordering). When the range drops, the fob battery is usually the first thing to change.
CR2032 for Motherboard CMOS
The motherboard CMOS battery keeps your BIOS settings and system clock powered when the PC is off. Many desktop boards and laptops use a CR2032 — a dead cell is the usual cause of a "wrong system time" or lost BIOS settings on boot.
CR2032 for Apple AirTag
The Apple AirTag runs on a removable CR2032 coin cell. To replace it: press and twist the back cover open, swap the old cell for a fresh CR2032, then re-seat the cover. A new CR2032 keeps your AirTag powered and alerts you when it gets low.
What do buyers ask about the CR2032 battery?
Need the CR2032 priced, or the same cell printed and packed under your own brand? Send the quantity, the target market and the packaging format, and we return price, MOQ band and the CR2032 data sheet.
Printed, blister-carded and boxed in our own plant, from 50 cartons per product line. Samples are available before a production run — tell us the device the cell goes into.
CR2032 Battery FAQs
What is a CR2032 battery?
What is the CR2032 compatible with?
What is a CR2032 battery equivalent to?
Is the CR2032 rechargeable?
How long does a CR2032 battery last?
Does a CR2032 fit my device?
How do I get CR2032 battery wholesale pricing?
Pricing depends on cell grade, quantity and packaging, so quotes are issued per project rather than from a fixed list. Send your quantity, target market and label or packaging requirements, and we return a landed-cost quote together with samples — usually within one working day.
Which batteries are related to the CR2032?
These models share chemistry, voltage or form factor with the CR2032 and are frequently specified alongside it. Where a device accepts more than one size, confirm the battery-bay dimensions before ordering — each card below links through to the full specification and equivalents.
